ILCO Speed 040 Automatic / Manual Duplicator

The Speed 040 is primarily an automatic model that also provides the flexibility to be operated manually when desired to duplicate edge cut/flat style keys accurately.

The Speed 040 is the perfect choice for the store or shop wanting the versatility to choose between manual or automatic operation. This versatile operational mode combined with the modern, open style and many additional features will supply users with years of service.

• The spring loaded carriage is engaged by the press of a button and applies a consistent cutting pressure while in automatic mode
• Slotted jaw surfaces accommodate tip stop bars and a rigid shoulder gauge design to allow for greater accuracy when loading and gauging keys.
• Four sided, nickel plated jaws for clamping the majority of all edge cut/flat type keys. Smooth rotation by simply twisting into position.
• Wide spacing 3 1/2” (88.9 mm) spacing between clamps accommodate large bow (head) and long blade keys, including flip style keys
• TiN (Titanium Nitride) coated cutter for longer life and oxidation resistance
• Depth tracer system with micro adjustment for precise calibration in increments of .00098” (0.025mm)
• Nylon deburring brush
• Electro-magnetic “main” safety switch with a separate cutter motor switch for easy access.
• Large drawer-type swarf (chip) tray under the carriage for easy access
• Large transparent cutter safety shield contains chips and provides a storage area for accessories
• Mounting bracket included for securing the machine to counter
• Two year warranty

Power Supply: 120V-60Hz
Maximum absorbed power: 2.8 Amp, 200 Watt
Cutter motor: single phase and speed
Tool Speed: 1350 rpm
Movements: by ball joint on rectified carriage
Carriage Runs: 1.65” (42 mm)
Brush: Nylon, 5/8” (15.87 mm) bristles
Cutter: TiN coated
Dimensions: Width: 19.3” (490 mm)
Depth: 18.1” (460 mm)
Height: 11.8” (300 mm)
Weight: 44 lbs. (20 kg)
